 STABLE CONSTRUCTION
The operation reliability and simplicity closed in a solid design. Our ploughs combine these features and they will certainly meet your requirements. The proper ground clearance under the frame of up to 76 cm and the spacing of the bodies (of up to 85 cm or 100 cm) guarantee the coverage of significant amounts of agricultural crop residues and secondary crops. The use of the high quality steel let obtain a very durable design at the total machine mass the least in its class. The frame (140x140 mm profile) made of improved and heat-treated steel ensures that the plough manages even in the heavy conditions. Due to our experiences, satisfied customers’ opinions and continuous tests we can create new solutions which lead to the next generation of rotary ploughs. |
 ROTARY PLUGH
It is only one direction, i.e. to limit the production costs. The future of the direction of the plant production that you have selected is safe with the solid, effective and not expensive machines. The PO series ploughs ensure a fast return of the incurred expenses and allow focusing on the crops. The conception of rotary plough is consistent with an idea of effective and quick ploughing without unnecessary downtime. Ploughing is the first agricultural measure. This is just the beginning of the road. Hit the road only with the experienced partner. Go ahead with us. AGRO-MASZ engineers developing the conception of rotary ploughs focused on using the latest available technical solutions, such as the heat-treated frame and the design based on the bolted connections for the extension of the machine lifetime which guarantees reliability for a long time. |
 EFFECTIVE
A light design means lower fuel consumption, so low costs at the beginning. Furthermore, the long lifetime of the working subassemblies ensures low operational costs. AGRO-MASZ uses advanced steel processing technologies in the production of its ploughs in order to obtain the optimum durability of working subassemblies. The difference is invisible to the eye but it is tangible with every hour of the work in the field. |
 VARIABLE WIDTH
The ploughing performance and tractor combustion level depend to a large extent on the working width of the plough. The ploughing width in our ploughs can be changed in a simple manner, by shifting the position of adjusting bolt which determines the work width of every furrow-slice. The working width of the plough can be adjusted to the tractor power and type without unnecessary efforts. The four-stage scale of the gradual work width adjustment of every body within 35, 40, 45, 50 cm gives huge opportunities. The width reduction can be forced by changing soil conditions. The width can be also increased to the maximum when shallow ploughing is required. The tractor power and parameters can be fully used in very changing conditions as well. |
 LATERAL ADJUSTMENT
An angle of plough inclination is set separately for every side. A simple arrangement of the bolts located by the machine head guarantees the uniform work of the left and right bodies. The set work position (angle) of the left and right bodies is locked by securing the hinged holders. |
 HEAD WITH DRAWBAR
A new design of the head of the second generation of the rotary ploughs meets the increasing requirements. The plough comes up with the heavy conditions cooperating with the new types of tractors. The maintenance-free operation for years is attributed to the pivot with an increased diameter, made in the patented technology, seated onto the system of twin needle bearings. The swing cylinder located behind the plough turret is responsible for a smooth rotation of the plough. Due to the light design and the optimum movement of the centre of gravity of the machine the revolution is made quickly without distorting the stability of the assembly. There is a drawbar of the 2nd and 3rd category available for the best adjustment to your tractor. Furthermore, to move optimally the centre of gravity of the plough towards the tractor the bar can be blocked in one of four positions. |
 BODY AND INSERT FOR ALL SOIL
The bodies designed to prove useful in deep ploughing from 15 to 35cm for working widths of 35-50cm per every furrow-slice perform well even at the speeds of up to 10km/h. The work of every body produces an effect of aligned furrow edges with full turnover of every furrow-slice even where large amounts of organic residues prevail. This is largely due to the cylinder and bolt mouldboards which show little resistance and additionally greatly affect the reduction of fuel consumption.The bodies work well also while crushing larger soil lumps. The shearing slats, mounted on every body as standard, prove useful on the soils where large amounts of agricultural crop residues prevail, not reducing the ground clearance between the bodies as in case of skim coulters, thus do not imply a risk of machine clogging.
You will certainly appreciate simple bolt adjustment of mouldboard and angle of approach of the entire body, in particular when using low fuel consumption as a benchmark of effective work. |
 PROTECTION AGAINST STONES
The semi-automatic protection has been the missing link in our offer to this day. The perfect compromise between shear and spring protection. For each type of soil, in conditions of fields not stony or slightly stony. |
 WIDTH ADJUSTMENT OF THE FIRST FURROW-SLICE
As for the adjustment we are guided by one principle: simplicity. Only the uncomplicated adjustment systems of the plough parameters allow focusing on the work and not on the verification of the machine operation. The alignment and width adjustment of the first furrow-slice (in the parallelogram system) is performed by means of the turnbuckles. The optimum pulling point is achieved in a simple manner. However, if you prefer the highest level of the operational comfort you can choose a plough with the hydraulic alignment adjustment where the cylinder is equipped with a sequential valve that supports additionally the revolution process, narrowing the machine and transferring the copied adjustment of the plough work from the left-hand bodies to the right-hand bodies and vice versa.
This is the simple adjustment according to our conception. |
REAR WHEEL (TRANSPORT AND DEPTH WHEEL) 10.0/80 R12
SIDE WHEEL (TRANSPORT AND DEPTH WHEEL) 10.0/80 R12
