ID # 40583997

Dewulf SB 451

Call for Price
Overview

Receiving hopper of 10 m³

Small variant with big capacities

The SB 451 is a small receiving hopper with large capacities and has a bunker capacity of 10-12 m³. This product-friendly receiving hopper can be equipped with a combination of various options both in the field of cleaning and sorting.

The driving force for your storage process

The Miedema receiving hoppers form the basis for reliable storage with the desired buffer, transport, cleaning and sorting capacity. Our receiving hoppers are your guarantee for product-friendliness and versatility. And most importantly: The operating costs always remain enjoyably low.

Compact and productive at the same time

The SB series is the most compact series within our product range of Miedema receiving hoppers. Nevertheless, the SB receiving hoppers can realise a high capacity of up to 150 tonnes per hour. Thanks to the machine options, these receiving hoppers can be perfectly attuned to the respective local conditions. The SB series is characterised by a robust construction of the bunker chassis. The heavy-duty, especially hardened bunker chains guarantee a maximum service life with a minimum degree of maintenance. Loss of product is prevented by the bunker’s especially high side boards and the sturdy double rubber flaps for a perfect seal of the supply. The SB Series’ design has already proven its worth on many farms.



Specifications
Model
SB 451
Category Name
Agriculture
Year
2026
Sale Type
New
Manufacturer
Dewulf
Entry Width [cm]
295
Live Bottom Width [cm]
160
Live Bottom Length [cm]
350
Live Bottom Speed [m/min]
0,1 - 4,6
Maximum Driving Speed [km/h]
6
Effective Hopper Volume [m³]
10 - 12 m3
Height [cm] (depending On The Options)
270 - 370
Largest Width [cm] (without Discharge Belts)
311
bunker
 ■ = standard o = Optional - = Not applicable

Variable input board o
Start/Stop with IR sensor level control o
Onion mill o
SB-Control o
Start-Control functionality
cleaning and sorting
 ■ = standard o = Optional - = Not applicable

Flow-Pin o
Smart-Pin o
Roller unit with 6 or 8 rollers o
2nd roller unit with 6 rollers o
2nd roller unit with 8 rollers o
Roller unit with chain drive, 2 speeds
Star rollers with 7 or 11 fingers o
Smooth rollers o
Metal or PU coil rollers o
Sorting rollers o
Guide on product discharge belt o
Inspection table -
Power outlet (20 A) on machine o
